Traveller, clubman, estate van & pick up : Somerford Mini

Companion Boxes
Companion boxes came in two different guises, depending on door type, seatbelt mounting type (if any) and ashtray fitment (if any).
Ill. No.	Part No.	Description	Qty. Rqd.	Remarks
1	24A565	COMPANION BOX ASSY., RH, with ashtray	1	For externally hinged door models.
2	24A566	COMPANION BOX ASSY., LH, with ashtray	1	For externally hinged door models.
	REPAN076	COMPANION BOX ASSY., RH	1	For externally hinged door models; non-genuine.
	REPAN075	COMPANION BOX ASSY., LH	1	For externally hinged door models; non-genuine.
3	CZH308	COMPANION BOX ASSY., RH, with seatbelt mounting	1	For internally hinged door models.
	CZH309	COMPANION BOX ASSY., LH, with seatbelt mounting	1	For internally hinged door models.
	REPAN150	COMPANION BOX ASSY., RH	1	For internally hinged door models; non-genuine.
	REPAN149	COMPANION BOX ASSY., LH	1	For internally hinged door models; non-genuine.
4	REPAN114	COMPANION BOX REPAIR, RH	1	For externally hinged door models; non-genuine.
	REPAN115	COMPANION BOX REPAIR, LH	1	For externally hinged door models; non-genuine.
5	REPAN201	COMPANION BOX REPAIR, RH	1	For internally hinged door models; non-genuine.
	REPAN202	COMPANION BOX REPAIR, LH	1	For internally hinged door models; non-genuine.
6	REPAN127	BRACKET, companion box ashtray, RH	1	Non-genuine.
	REPAN128	BRACKET, companion box ashtray, LH	1	Non-genuine.
7	CZH3175	BRACKET, seat belt mounting	2
8	CZH216	TUBE, reinforcement	2	Included in mounting bracket.
9	REPAN125	STIFFENER, inner sill, RH	1	Non-genuine.
	REPAN126	STIFFENER, inner sill, LH	1	Non-genuine.

Rear Floor Assembly
Traveller, Countryman, Clubman Estate and Van with Wooden Load Floor
There were three variations of this rear floor:

1960 Traveller and Countryman - with the fuel tank on the LH side of the luggage floor and the battery in a box, saloon-style, next to the spare wheel.

1961 on Traveller, Countryman and Clubman Estate - underfloor fuel tank and the battery under the rear seat cushion on the front floor.

Van with Wooden Load Floor - fuel tank and battery in same positions as 1961 on Traveller and Countryman, but larger load (luggage) board.

Ill. No.	Part No.	Description	Qty. Rqd.	Remarks
10	24A605	REAR FLOOR PANEL	1	1961 on; can be adapted for 1960 Traveller and Countryman.
11	REPAN048	REAR FLOOR REPAIR, front corner, RH	1	Non-genuine.
12	REPAN049	REAR FLOOR REPAIR, front corner, LH	1	Non-genuine.
13	REPAN042	REAR FLOOR REPAIR, side, RH	1	Non-genuine.
	REPAN043	REAR FLOOR REPAIR, side, LH	1	Non-genuine.
14	REPAN218	REAR FLOOR REPAIR, stepped corner, RH	1	Non-genuine.
	REPAN220	REAR FLOOR REPAIR, stepped corner, LH	1	Non-genuine.
15	REPAN219	REAR FLOOR REPAIR, stepped side, RH	1	Non-genuine.
	REPAN221	REAR FLOOR REPAIR, stepped side, LH	1	Non-genuine.
16	REPAN019	STEP, rear floor, full width	1	Non-genuine; includes corners.
17	REPAN082	STEP, rear floor, 3/4 width	1	Non-genuine; between door pillars only.
18	14A7993	BATTERY BOX ASSEMBLY	1	1960, Traveller and Countryman.
19	14A7404	LUGGAGE FLOOR SIDE, RH	1	1960, Traveller and Countryman.
	14A7405	LUGGAGE FLOOR SIDE, LH	1	1960, Traveller and Countryman.
20	14A7606	BRACKET, fuel tank securing, lower	1	1960, Traveller and Countryman.
21	14A8162	LUGGAGE FLOOR SIDE, RH	1	1961 on, Traveller and Countryman. Clubman Estate.
	14A8163	LUGGAGE FLOOR SIDE, LH	1	1961 on, Traveller and Countryman. Clubman Estate.
22	14A9016	FLOOR SIDE ASSEMBLY, front, RH	1	Van with wooden load floor.
	14A9017	FLOOR SIDE ASSEMBLY, front, LH	1	Van with wooden load floor.
23	12K661	SPRING, Dzus	2	Van with wooden load floor.
24	5C2424	RIVET, spring to floor side	4	Van with wooden load floor.
25	14A9011	ANGLE, floor side to wheel arch	2	Van with wooden load floor.
26	RTZ1004	SCREW, floor side securing	4	Van with wooden load floor.
27	PTZ1004	SCREW, floor side securing	4	Van with wooden load floor.
28	PFS410	NUT, spire	6	Van with wooden load floor.
29	CZH3314	RAIL, load floor support, rear	1
30	14A7406	RAIL, load floor support, front, upper	1
31	14A8160	RAIL, load floor support, front, lower	1
32	88G479	BOSS, spare wheel clamp	1	1960-68.
	REPAN007	BOSS, spare wheel clamp	1	1960-68; non-genuine.
33	14A7106	CLOSING PANEL, rear valance	1	Non-genuine.
34	14A8159	CHANNEL, rear floor, subframe mounting	1	Non-genuine.

Van with Metal Load Floor and Pick Up
Ill. No.	Part No.	Description	Qty. Rqd.	Remarks
35	REPAN078	REAR FLOOR COMPLETE ASSEMBLY	1	Van with metal load floor; non-genuine.
	REPAN079	REAR FLOOR COMPLETE ASSEMBLY	1	Pick Up; non-genuine.
36	REPAN083	REAR FLOOR PANEL	1	Van with metal load floor; non-genuine.
	REPAN092	REAR FLOOR PANEL	1	Pick Up; non-genuine.
37	REPAN089	HALF REAR FLOOR PANEL, RH	1	Van with metal load floor; non-genuine.
	REPAN093	HALF REAR FLOOR PANEL, LH	1	Van with metal load floor; non-genuine.
	REPAN094	HALF REAR FLOOR PANEL, RH	1	Pick Up; non-genuine.
	REPAN095	HALF REAR FLOOR PANEL, LH	1	Pick Up; non-genuine.
38	REPAN096	REAR FLOOR REPAIR, heelboard forwards	1	Non-genuine.
39	REPAN097	REAR FLOOR REPAIR, heelboard rearwards	1	Van with metal load floor; non-genuine.
	REPAN098	REAR FLOOR REPAIR, heelboard rearwards	1	Pick Up; non-genuine.
40	REPAN099	REAR FLOOR REPAIR, rear corner, RH	1	Non-genuine.
	REPAN100	REAR FLOOR REPAIR, rear corner, LH	1	Non-genuine.
41	REPAN218	REAR FLOOR REPAIR, stepped corner, RH	1	Non-genuine.
	REPAN220	REAR FLOOR REPAIR, stepped corner, LH	1	Non-genuine.
42	REPAN219	REAR FLOOR REPAIR, stepped side, RH	1	Non-genuine.
	REPAN221	REAR FLOOR REPAIR, stepped side, LH	1	Non-genuine.
43	14A7120	RAIL, rear floor, front	1
44	14A7180	FINISHER, rear floor, front	1
45	GFK7515	CLIP, finisher to rear floor	10
46	REPAN019	STEP, rear floor, full width	1	Non-genuine; includes corners.
47	REPAN082	STEP, rear floor, 3/4 width	1	Non-genuine, between door pillars only.
48	14A7106	CLOSING PANEL, rear valance	1	Non-genuine.
49	REPAN101	BRACKET, tailboard hinge mounting	2	Pick Up; non-genuine.
50	REPAN124	CHANNEL, rear floor, subframe mounting	1	Non-genuine.
51	REPAN020	CLOSING PANEL, rear floor channel, RH	1	Non-genuine.
	REPAN021	CLOSING PANEL, rear floor channel, LH	1	Non-genuine.
52	REPAN106	REINFORCEMENT ASSEMBLY, rear floor	1	Non-genuine.

Rear Wheel Arches
Ill. No.	Part No.	Description	Qty. Rqd.	Remarks
53	14A9560	REAR WHEEL ARCH ASSEMBLY, RH	1
	14A9561	REAR WHEEL ARCH ASSEMBLY, LH	1
	14A9558	REAR WHEEL ARCH ASSEMBLY, RH	1	Alternative; saloon type. May be used on other body styles.
	14A9559	REAR WHEEL ARCH ASSEMBLY, LH	1	Alternative; saloon type. May be used on other body styles.
Wheel arches for the long wheelbase Minis (the various estate, van and pick up models) are subtly different in the shock absorber mounting area from their saloon counterparts. This does preclude the fitment of some types of shock absorber to these models - most commonly gas adjustable types. The problem can be solved by fitting saloon wheel arches, or the HMP441010 and HMP441011 wheel arch inner assemblies listed below. A very minor amount of floor modification should be anticipated to make the saloon wheel arches fit.

Ill. No.	Part No.	Description	Qty. Rqd.	Remarks
54	14A6617	REAR WHEEL ARCH OUTER PANEL, RH	1
	14A6618	REAR WHEEL ARCH OUTER PANEL, LH	1
55	HMP441010	REAR WHEEL ARCH INNER ASSEMBLY, RH	1	Saloon type; may be adapted to fit other body styles.
	HMP441011	REAR WHEEL ARCH INNER ASSEMBLY, LH	1	Saloon type; may be adapted to fit other body styles.
56	14A6611	CLOSING PANEL, heelboard to arch, RH	1	Not Van with metal load floor or Pick Up.
	14A6612	CLOSING PANEL, heelboard to arch, LH	1	Not Van with metal load floor or Pick Up.
57	14A7155	EXTENSION, rear wheel arch, RH	1
	14A7156	EXTENSION, rear wheel arch, LH	1
58	14A7545	REAR SEAT SQUAB SUPPORT, side, RH	1	Traveller, Countryman and Clubman Estate.
	14A7546	REAR SEAT SQUAB SUPPORT, side, LH	1	Traveller, Countryman and Clubman Estate.
59	14A7547	REAR SEAT SQUAB SUPPORT, top, RH	1	Traveller, Countryman and Clubman Estate.
	14A7548	REAR SEAT SQUAB SUPPORT, top, LH	1	Traveller, Countryman and Clubman Estate.
60	14A7604	BRACKET, fuel tank securing, upper	1	1960, Traveller and Countryman.

Wiring Tags and Service Clips
For an explanation of wiring tags, please see the text in the ‘Dash Assemblies - All Models’ section.
Ill. No.	Part No.	Description	Qty. Rqd.	Remarks
61	CW100110	WIRING TAG, short	A/R
62	CW100120	WIRING TAG, long	A/R
63	ALA5537	SERVICE CLIP, rear floor	1
